KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor

Products - Optical Video Measurement System

Highlight

Automatic Video Measurement System
,
Fixed Bridge Video Measurement System
,
Servo Motor Video Measurement System
Travel

600x600x200mm
Structure

Fixed-bridge
Base Material

Marble
Resolution

0.5µm
Lens

6.5X
Magnifier Rate*1

20X-126X(0.7X-4.5X)
Dimensions(mm)

1650×1250×1650
Instrument Weight (kg)

920kg
Place of Origin

Guangong/China
Brand Name

koqia
Certification

CE
Model Number

KV-S-662
Minimum Order Quantity

1 Sets
Price

Can be discussed
Packaging Details

Plywood
Delivery Time

30 work days
Payment Terms

L/C,T/T
Supply Ability

100 Sets/Month

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor

Name: KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor
Brand: Koqia Measuring Instrument Inc
SKU: KV-S-662
Availability: InStock

button button

Get Price Contact Now

KV-S-662 Servo Motor Fixed-bridge Automatic Video Measurement System

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 0

Product Introduction:

【 KV-S 】Series servo motor fixed bridge automatic measuring instrument, preferably high-density granite workbench, high compressive strength, low water absorption, high surface hardness and other advantages, combined with the self-developed load-bearing platform to ensure that the workpiece has no displacement during operation, and the stability is better;

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 1

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 2

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 3

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 4

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 5

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 6

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 7

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 8

Basic Functions:

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 10

Measurement Function:

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 11

Fields of Application:

KV-S-662 Fixed Bridge Automatic Video Measurement System With Servo Motor 12

Specifications:

Model		KV-S-332	KV-S-442	KV-S-552	KV-S-662
Travel	X(mm)	300	400	500	600
	Y(mm)	300	400	500	600
	Z(mm)	200	200	200	200
Structure		Fixed-bridge
Base Material		Marble
Monitor		24-inch LCD Monitor
Image Sensors		1/2" digital CCD, high pixels, global color, large field of view
Resolution		0.5µm
Lens		6.5X
Magnifier Rate*1		20X-126X(0.7X-4.5X)
Lighting system	Transmitted Light	LED Telecentric Transmission Ilumination
	Surface Light	5 Rings and 8 Zone Split light
	Coaxial Light	Optional, LED light
Detection Accuracy*2	X/Y-axis	(1.8+L/200)µm	(2.0+L/200)µm	(2.2+L/200)µm	(2.4+L/200)µm
	Z-axis	(5.0+L/200)µm
Maximum Speed	XY(mm/s)	300 mm/s
	Z(mm/s)	100 mm/s
Dimensions(mm)		1150×850×1650	1350×950×1650	1550×1050×1650	1650×1250×1650
Instrument weight (kg)		620kg	710kg	810kg	920kg
Load-bearing (kg)		25kg
Power Supply		1600W
Sensor Configuration		Optional, (1) point spectral sensor; (2) Line laser sensor; (3) contact probe;
Motion Control		Servo Control System
Measurement Software		GQuick Series
Operating Voltage		AC 220V,50/60Hz or others
Working Environment		Temperature 20°C ±3°C, humidity 35~75%

*1 Image magnification is approximate and depends on the size and resolution of the display
*2 At the focusing position, when the ambient temperature is 20°C ± 3°C, the weight mounted on the stage is 5 kg or less, and L is the stage movement (mm)
